Place of Origin: | Jiangsu, China |
---|---|
Marca: | KAD |
Minimum Order Quantity: | 1 |
Preço: | $1,376.19 |
Fork Length: | 1220-1520mm | Fork Width: | 160-180mm |
---|---|---|---|
Load Capacity: | 1500kg | Lifting Height: | 1-5m |
Battery Voltage: | 24V | Battery Capacity: | 100Ah |
Drive Motor Power: | DC/0.75KW | Lifting Motor Power: | DC/2.2KW |
Driving Speed: | 5.0 MM/S | Lifting Speed: | 140/135 MM/S |
Descending Speed: | 150/155 MM/S | Max Gradient: | 7/5° |
Turning Radius: | 1390 MM | Wheel Material: | PU |
Brake Type: | Electromagnetic brake | ||
Destacar: | 1500kg electric walkie stacker,electric pallet stacker 1-5m lift,walkie stacker forklift with warranty |
Attribute | Value |
---|---|
Applicable Industries | Building Material Shops |
Condition | New |
Terrain Adaptability | Indoor Flooring, Outdoor Pavement, other |
Power Source | DC MOTOR |
Drive Type | other |
Fork Length | 1220-1520mm |
Fork Width | 160-180mm |
Warranty | 1 Year |
Type | Stacker Forklift |
Load Capacity | 1500kg |
Product Name | walkie electric stacker |
Lifting height | 1-5m |
Capacity | 1.6tons |
Battery | 24V100Ah |
Mast | customization |
Model | CDDW10 CDDW15 | |||
---|---|---|---|---|
Drive system | Battery | |||
Driving mode | Walkie | |||
Load Capacity | Q | KG | 1000 | |
Load Center | C | MM | 500 | |
Weight(With battery) | KG | 480/495/515/535 | ||
Wheels Material | PU | |||
Lifting Height | H3 | MM | 1600/2000/2500/3000/4000 | |
Lowest Mast | H1 | MM | 2080/1580/1830/2080/1580 | |
Max.Height when operating | H4 | MM | 2080/2730/3230/3730/4750 | |
Min.Height of Fork | H13 | MM | ≤90 | |
Length | L1 | MM | 1770 | |
Width | B1 | MM | 850 | |
Fork Length | L | MM | 1070 | |
Wheelbase | Y | MM | 1250 | |
Fork Outside Width | B5 | MM | 680 | |
Fork Inside Width | MM | 305 | ||
Min.Turning Radius | WA | MM | 1390 | |
Driving Speed (Empty/Full Load) | MM/S | 5.0/5.0 | ||
Lifting Speed (Empty/Full Load) | MM/S | 140/135 | ||
Descending Speed (Empty/Full Load) | MM/S | 150/155 | ||
Max.Gradient (Empty/Full Load) | ° | 7/5 | ||
Brake | Electromagnetic brake | |||
Driving Motor | KW | DC/0.75 | ||
Lifting Motor | KW | DC/2.2 | ||
Battery Capacity | V/Ah | 24/80/100;Li/gel |
