Electric Pallet Stacker with 500mm Load Center 1070mm Fork Length and 1738/2099mm Turning Radius

Informação Básica

Quantidade de ordem mínima:	1
Preço:	2885

Melhor preço contacto

Modelo No.:	CDD1516	Capacidade de carga:	1 a 1,5 t
Centro de carga:	500mm	Altura de elevação:	1600mm
Peso bruto:	900.000kg	Capacidade da bateria:	24v/210Ah
Largura da forquilha:	850 mm	Girando raio:	1738/2099 mm
Comprimento do garfo:	1070 mm	Motor de acionamento:	1.2kW
Motor de elevação:	2.2kW	Tamanho do pneu:	300/250mm
Tamanho geral:	217015702100 mm	conduzindo a velocidade:	4km/h
Inclinação:	3°/5°
Destacar:	500mm Load Center Electric Pallet Stacker , 1070mm Fork Length Full Electric Stacker , 1738/2099mm Turning Radius Electric Forklift

Great Electric Pallet Stacker Balance Battery Forklift DC Drive Motor

Full electric stackers are designed for loading, stacking, and short-distance palletizing of goods. Featuring a simple structure and flexible operation, they offer excellent micro-operability and high safety performance. Ideal for operations in narrow passages and limited spaces, these stackers can efficiently work in ship cabins, carriages, and containers for pallet goods handling.

Product Specifications

Model	CDD1030	CDD1530
Load Capacity	1000 kg	1500 kg
Lifting Height	3000 mm	3000 mm
Load Center	500 mm	500 mm
Fork Size	1220×100×40 mm	1220×100×40 mm
Ground Clearance	30 mm	30 mm
Driving Speed with Full Loads	4 km/h	4 km/h
Battery	24V/210A	24V/210A
Driving Motor	1.2 KW	1.2 KW
Lifting Motor	2.2 KW	2.2 KW
Overall Size	2170×1570×2100 mm	2170×1570×2100 mm
Weight	900 kg	900 kg

Detailed Photos

Machine Components

Control Handle: KAD brand domestic famous control handle with functional buttons for sensitive UP/DOWN, FORWARD/BACKWARD control.

Operation Panel: Features key, battery indicator, and emergency switch. The functional panel with beautiful design enhances work efficiency and ease.

Mast System: Strong cylinder and chain ensure smooth fork operation. Available in 1-stage, 2-stage, or 3-stage mast configurations.

Key Features

Side-positioned drive system and strong caster provide exceptional stability and easy maneuverability.

Frequently Asked Questions

Q1. What is your terms of packing?

A: Generally, we pack our goods in paper package and Iron pallet. We can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or as negotiated.

Q3. What is your terms of delivery?

A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?

A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.

Q5. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q6. How do you make our business long-term and good relationship?

A: 1. We keep good quality and competitive price to ensure our customers benefit;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
